Inline PoE Surge Protector

SKU SP200
614395004576
No reviews yet | Write A Review

AED247.00

The Triplett Model SP200 is an Inline PoE Surge Protector is designed to protect valuable PoE devices in Educational Institutions, Server Farms, Manufacturing Facilities, and other installations from from high voltage surges. In addition, it provides ESD protection to 30kV and lightning protection to 10kV. It features a 10/100Mbps bandwith, response time of less than 1ns, and a surge life of 300 times (100A per surge@8/20µs). IEEE 802.3af, IEEE802.3at, and IEC 61000-4-5 2nd edition compliant. Includes external ground wire.

Weight 0.25 kg
Dimensions 4.5 × 1.5 × 4.25 cm
  • Designed to protect a valuable PoE device from high voltage surges
  • Response time less than 1 ns
  • Supports bandwidth up to 100Mbps
  • Supports IEEE 802.3af, IEEE 802.3at PoE Standard
  • Supports Mid-span and End-span

Product Group:  POC/POE

Product Type: PoE Surge Protectors

Includes: Includes external ground wire

Harmonization Code: 8504.90.6500

ECCN: EAR99

Packaging: Box

Weight lbs to kg: 0.25

Length in: 4.5

Width in: 1.5

Height in: 4.25

SP200
Compliance IEEE 802.3af, IEEE802.3at, IEC 61000-4-5 2nd edition
Network Bandwidth 10/100Mbps
Response Time Less than 1ns
ESD Protection 30kV (Air, Contact)
Lightning Protection 10kV@8/20µs, 10kV@10/700µs
Surge Life 300 times (100A per surge@8/20µs)
Insertion Loss Less than 0.2dB
Returm Loss (75Ω) -16dB
Input RJ45
Output RJ45
Dimensions 3.5 x 1 x 1″ (88.8 x 25.4 x 25.4mm)
Weight 2.8oz (80g)
Data SheetUser Manual
